Blackbird™ by Monoprice™
4K HDMI® 2x4 Dual Function Splitter and Switch
Distribute video from either of two sources to four displays
The Monoprice™ Blackbird™ 4K HDMI® 2x4 Dual Function Splitter and Switch has two HDMI inputs and four HDMI outputs, allowing you to switch between either of two input source devices and send the signal to all four display outputs. It features a built‑in, automatically adjusting video amplifier, which allows you to use longer than normal HDMI cables without any signal loss or degradation.
It supports video resolutions up to 4K@60Hz with high‑definition, multichannel audio, including DTS Digital™, Dolby Digital™, DTS-HD Master Audio™, and Dolby TrueHD™, as well as standard 7.1‑channel LPCM stereo. It delivers up to 18Gpbs video bandwidth, supports the YCbCr 4:4:4 color space, and provides basic EDID® management.
IMPORTANT: This is NOT a Matrix device and will not allow mixing input sources between output displays. To see various Matrix devices, please click here.
- Distributes either of two HDMI® sources to all of four HDMI displays
- Complies with the HDMI 2.0b and HDCP™ 2.2 specifications
- Supports HDMI® resolutions up to 4K@60Hz with the 8‑bit RGB, YCbCr 4:4:4, and YCbCr 4:2:2 color spaces
- Supports high‑definition digital audio formats, including LPCM 7.1, Dolby Digital™, Dolby TrueHD™, DTS Digital™, and DTS‑HD Master Audio™
- Supports HDR10, HDR10+, HLG, and Dolby Vision™
- Includes basic EDID® management
