5520 Versatile Interface Module with 4 x 10 & 25GB SFP28 MA Csec-Capable Ports - 4 Year

4-Port POE Plus 10-100 2-Port 10-100 2-Port SFP Ethernet Switch

Our high quality products enable reliable connectivity in any condition or area. These products are designed to be easy to use, reliable and safe and cater different applications with desired performance.

• Constructed of a high strength composite material
• Long lasting durability

• Port: 2 & 4
• Operating Temperature: -40C to +75C
• Network Technology: 10/100
• Weight: 2.9 lbs

The ES0152P is a feature-rich managed switch for ATEN KE series KVM over IP extenders and VE89 series Video over IP extenders. Ideal for installation in combination with the KE - VE89 series products, the ES0152P helps users build their OT infrastructure with the KE series by eliminating the hassles of complicated setup.

Deploying the ES0152P is fast and easy. With everything plug and play, there is no need to install software or configure devices. Simply connect the KE - VE89 transmitters and receivers to the ES0152P using Cat 5e-6 cables and all KE - VE89 series devices on the same LAN will automatically be detected.

The ES0152P network switch provides a 52-port, high-performance configuration, a complete array of L2 features and advanced functionalities including Layer 3 static route, DHCP server, IPv6 support and LLDP, delivering a versatile solution for improving network performance.

The ES0152P offers a combination of SFP fiber and RJ45 copper ports for servicing a range of network needs. It supports 4 1G-10G SFP and 48 10M-100M-1G RJ45 with PoE Support 802.3at-af ports. Featuring Power over Ethernet function, the ES0152P can provide up to 740 Watts power budget across 48 RJ45 ports thus eliminating the need for a power adapter and effectively reducing the power configuration cost.

The ES0152P comes with embedded DMS functions to facilitate device management anytime and anywhere. Its intuitive, user-friendly interface enables IT administrators to set up and manage their networks and all the connected KE - VE89 devices effortlessly. It also has comprehensive security features such as IP source guard and ACL to guard your network from unauthorized access.

• Incorporates 48 RJ-45 10-100-1000 Mbps ports and 4 SFP uplink ports 10Gbps
• Automatically detects KE-VE89 series devices
• Plug-and-play without additional settings
• 802.3af PoE-802.3at PoE Port configuration and scheduling
• Auto detects KE-VE89 series devices
• Supports IGMP snooping fast leave
• Supports flow control
• Supports IGMP v1-v2-v3 snooping and IGMP v1-v2 querier
• High-performance Gigabit Ethernet L2 access switch with 176 Gbps switching capacity - significantly improve the responsiveness of applications and file transfer times
• Built in Device management system to provide an overview of all connected KE-VE89 devices for management
• Supports IEEE 802.1w rapid spanning tree protocol - ensuring a faster recovery from failed links and enhancing overall network stability and reliability
• Comprehensive QoS - allowing the marking, classification, and scheduling of up to four traffic types across the network
• Enhanced security - port security limits the total number of devices using a switch port and protects against MAC flooding attacks
• IPv4-IPv6 management

• 1x ES0152P 52-Port GbE PoE Managed Switch
• 1x AC Power Cord
• 1x RJ45 to DB9 Serial Console Cable
• 1x Foot Pad Set (4 pcs.)
• 1x Mounting Kit
• 1x User Instructions

• Rj-45 10/100/1000 Ports: 48
• SFP Uplink Ports: 4
• Console Ports: 1 x Rj45
• Switching Capacity: 176 Gbps
• Forwarding Rate: 130.95 Mpps
• Jumbo Frames: 10240 Bytes
• Maximum Input Power Rating: 100-240v Ac,50-60hz
• Power Consumption: AC 110v:885.36wbtu
• Standard Compliance: 802.3af Poe / 802.3at Poe+
• Number of Ports that Support Poe/Poe: 48
• Max. Poe Power Budget Per Port Poe: 15.4W
• Operating Temperature: 0-50 deg C
• Storage Temperature: -20-60 deg C
• Humidity: 10-90% Rh, Non-condensing
• Rack Space: 19"
• Housing: Metal
• Dimension: 1.73" H x 14.76" W x 17.4" L
• Weight: 12.33 lbs

Grow your business's network to support power over Ethernet compatible devices such as security cameras, VoIP phones, access points, and more with the UniFi Switch Enterprise 8 8-Port 2.5Gb PoE+ Compliant Managed Network Switch from Ubiquiti Networks. This managed switch features eight high-speed 2.5Gb Ethernet ports, each supporting up to 32W of power with a total budget of 120W. There are also two 10Gb SFP+ ports for fiber uplinks. Designed to blend into its environment, you can use the included hardware to mount the UniFi Switch Enterprise 8 on a wall or flat surface, where it will operate silently without causing a disturbance. Use the convenient 1.3" LCM color touchscreen to quickly configure, monitor, and troubleshoot your connections. Or you can manage your switch from almost anywhere using the UniFi Network app, which also includes an augmented reality feature that provides you with a visual overview of your port connections.

• Color: White
• PoE Budget: 120 W
• Input Voltage: 230 V AC
• Power Consumption: 150 W
• Material: Polycarbonate
• Dimension: 1.7 x 9.8 x 7.9 in.
• Weight: 5 lbs

• Easy access to all network configuration state information
• REST APIs for fine-grained programmability of network tasks
• A micro-services architecture that enables full integration with other workflow systems and services
• All software processes communicate with the database rather than each other, ensuring near real-time state and resiliency

• Up to 104 Gbps in non-blocking bandwidth and up to 77.3 Mpps for forwarding
