N-GXE-SC-02 3.3V Standard & LP 1000Base-X PCIE Gig...
The N-GXE-xx-02 Series is a Fiber Gigabit Ethernet to PCIe bus adapter that fully complies with all IEEE 802.3z and 1000Base-SX standards. It provides up to 2000 Mbps full-duplex bandwidth capacity to support high-end servers. In addition, with advanced functions like VLAN filtering packet processing, link aggregation, smart load balancing, fail-over, and Wake-on-LAN, the adapter provides enhanced performance, flexible configuration and secure networking for users in a standard-based environment. An LED indicator on the bracket displays link status, activity and speed.
Features- 3.3V Standard & LP 1000Base-X PCIE Gigabit Ethernet Fiber Network Interface Cards
- Supports full-duplex mode
- Supports IEEE 802.3x and IEEE 802.3z Full-Duplex Flow Control
- Compliant with PCIe Rev 2.1 Interface
- Advanced Configuration and Power Interface (ACPI) Specification v2.0c
- Magic Packet Wake-up enable
- Intelligent Interrupt Generation
- Standard bracket attached, low-profile bracket included
- Supports identification of NIC when multiple cards are installed
- Weight: 0.2 lbs
10.1 in. Smart 24-port GE PoE Switch
From connectivity to cloud applications, networking plays a crucial role in every business journey. Reliability, security, and affordability continue to be priorities, while ongoing management and operations add additional complexity that takes time and resources. Business is a portfolio of affordable wireless access points, switches, and routers designed and built for Small Business. Managed through Cisco Business Dashboard and mobile app, the portfolio provides a simple and reliable experience. Cisco Business Dashboard simplifies traditional challenges in deploying and managing business networks by automating the deployment, monitoring, and lifecycle management of the network.
Features- CBS220 Smart 24-port GE, Full PoE, 4x1G SFP
- Product Type: Ethernet Switch
- Manageable: Yes
- Ethernet Technology: Gigabit Ethernet
- Number of Total Expansion Slots: 4
- PoE (RJ-45) Port: Yes
- Expansion Slot Type: SFP (mini-GBIC)
- Power Consumption: 30.80 W
- Power Source: Power Supply
- Layer Supported: 2
- Environmentally Friendly: Yes
- PoE Budget: 382 W
- Height: 1.7"
- Width: 17.3"
- Depth: 10.1"
- Country Of Origin: Mexico
- Weight: 12.75 lbs
CBS220-24P-4X-NA 24 Port Gigabit PoE plus Complian...
Quickly expand your business's network capacity to support computers and other connected devices with the CBS220-24P-4X 24-Port Gigabit PoE+ Compliant Managed Network Switch from Cisco. This managed rackmount switch features 24 PoE+ compliant Gigabit Ethernet ports with a 195W budget to operate compatible devices such as IP security cameras, wireless access points, and VoIP phones. Its extensive Layer 2 features include link aggregation to create up to eight groups, each comprised of up to eight ports, for multi-Gig connections to compatible devices. Its 128 Gb/s switching capacity and 95.23 Mpps forwarding rate also help to ensure smooth and reliable data transfers. Use the Cisco Business Dashboard portal and mobile app to configure and monitor the Cisco CBS220-24P-4X and its connected devices. The dual-fan design helps to maintain optimal temperatures as the switch operates quietly in the background.
Specifications- Forwarding Rate: 95.23 Mpps
- Switching Bandwidth: 128 GB per Second
- Wattage: 195W
- Noise Level: 42.7 Db
- Country of Origin: Mexico
- Weight: 12.65 lbs
